HP Z440 Workstation Series Service Manual

HP Z640 Workstation system cabling
See
HP Z640 Workstation system board components on page 11 to determine the location of system board
connectors.
Cable To Cable/system board designator
PSU cable PCA P1(PWR) P1
PSU cable PCA P2(PWRMEM) P2
PSU cable First hard drive HDD BAY 0
PSU cable Second hard drive HDD BAY 1
PSU cable Third hard drive HDD BAY 2
PSU cable First optical drive D1
PSU cable Second optical drive D2
PSU cable First graphic card G1
PSU cable Second graphic card G2
Speaker PCA Pre-connected to FUI cable
CPU 0 HS fan cable PCA P8 (CPU 0 FAN) white
Rear fans cable PCA P11 (REAR FANS) white
MB memory fan cable PCA P91(MEM FAN) black blind-mate
Front fan cable PCA P9 (FRNTFAN) white
Front audio cable * PCA P28 (FRONT AUDIO) black
Front USB3.0 cable PCA P29 (FRNT USB3) blue
Front USB2.0 cable PCA P27 (FRNT USB2) yellow
Front UI cable PCA P5(PB/LED) black
Front 1394 cable PCA J12 (1394) white
Media card reader PCA P24 (I-USB2.0) blue
SAS card LED cable PCA P127 black
eSATA external connection PCA P64 (SATA4) black, P65 (SATA5) black
Hood lock cable PCA P124 (HOOD_LOCK) black
Hood sensor cable PCA P2 on FUI Cable, white
Serial option cable PCA P52 (COM) black
Second processor memory fan
cable
Riser PCA P9 (MEM_FAN) black blind-mate
* If an audio card is installed, connect the front audio cable to the audio card connector.
74 Chapter 3 Component replacement information and guidelines

HP Z440 Workstation Series Specifications

General

Chipset	Intel C612
Memory Slots	8 DIMM slots
Audio	Integrated Realtek HD ALC221 Audio
Processor Options	Intel Xeon E5-1600 v3 series; Intel Xeon E5-2600 v3 series
Memory	Up to 128 GB DDR4-2133 ECC
Graphics Options	NVIDIA Quadro or AMD FirePro professional graphics cards
Power Supply	700W 90% efficient, wide-ranging, active Power Factor Correction (PFC)
Operating System	Windows 10 Pro, Windows 7 Professional, or Linux
Weight	11 kg
Network	Integrated Intel I218LM PCIe GbE
Expansion Slots	1 PCIe Gen2 x1, 1 PCI
