HP Z440 User Manual

NOTE: Monitors with resolutions above 1920 x 1200 pixels at 60 Hz require a graphics card with
either Dual Link DVI (DL-DVI) or DisplayPort output. To get native resolution with DVI, you must
use a DL-DVI cable, not standard DVI-I or DVI-D cables.
HP workstations do not support all graphics cards. Be sure that a new graphics card is supported
before purchasing it. See
Finding supported graphics cards on page 15.
Many graphics cards provide more than two monitor outputs but limit you to using only two at a
time. Consult the graphics card documentation or look up information on the card according to the
procedure in
Finding supported graphics cards on page 15.
Some graphics cards support multiple monitors by multiplexing the monitor signal across multiple
outputs. This might reduce graphics performance. Consult the graphics card documentation or
look up information on the card according to the procedure in
Finding supported graphics cards
on page 15.
Make sure the card outputs match the input required by the monitors. (See
Identifying monitor
connection requirements on page 16.)
The different models of HP Z series Workstations have different limits on the mechanical size,
data speed, and power available for additional graphics cards. Note that the usual practical limit
for graphics cards is two per workstation. See the Maintenance and Service Guide for expansion
card slot identification to make sure a new graphics card will work for your workstation.
3. If you want to add a new graphics card or cards:
a. Determine which supported graphics card best fits your needs in terms of number of monitors,
compatibility with the monitors you plan to use, and performance. See
Finding supported graphics
cards on page 15.
b. Make sure you have the correct drivers for the card. See
http://www.hp.com for HP-qualified
drivers.
c. Install the graphics card according to the video instructions for your workstation at
http://www.hp.com/go/sml.
d. Configure the monitor. For details, refer to Microsoft® Help or to
http://www.microsoft.com.
For monitor setup in Linux, you can often use the settings tool for the graphics cards (e.g., NVIDIA
nvidia-settings or AMD Catalyst Control Center). In some recent Linux releases, the window
manager system (e.g., Gnome 3) preferences must also be modified.
TIP: To simplify troubleshooting of possible problems, enable the monitors one at a time: enable
the first monitor and make sure it works properly before enabling the next monitor.
Finding supported graphics cards
To find information about graphics cards supported for your workstation:
1. Go to
http://www.hp.com/go/qs/.
2. Select Search active QuickSpecs, and then select Desktops & Workstations.
3. Choose your model to view the specifications.
4. Click the link for Technical Specifications-Graphics to display expanded technical information for
supported graphics cards, including how many monitors the card supports, connectors, power
consumption, drivers, and other details.
Adding monitors 15

HP Z440 Specifications

General

Tcase	66.2 °C
Bus type	QPI
Stepping	R2
FSB Parity	No
Processor cache	10 MB
Processor cores	4
Processor model	E5-1620V3
System bus rate	0 GT/s
Processor series	Intel Xeon E5-1600 v3
Processor socket	LGA 2011-v3
Processor threads	8
Processor codename	Haswell
Number of QPI links	0
Processor frequency	3.5 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.6 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	1x4, 1x8, 1x16
Thermal Design Power (TDP)	140 W
Number of processors installed	1
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	1333, 1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	68 GB/s
Maximum internal memory supported by processor	768 GB
Memory slots	8x DIMM
Internal memory	16 GB
Memory channels	Quad-channel
Memory clock speed	2133 MHz
Maximum internal memory	128 GB
Memory layout (slots x size)	2 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express
Storage media	SSD
Optical drive type	DVD Super Multi
Total storage capacity	256 GB
BD interface type	SATA
Discrete graphics card model	Not available
Recovery operating system	Windows 8.1 Pro
Operating system installed	Windows 7 Professional
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
PS/2 ports quantity	2
USB 2.0 ports quantity	5
Chassis type	Mini Tower
Product color	Black
Country of origin	China
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® C612
Scalability	1S
Processor code	SR20P
Processor ARK ID	82763
Intel TSX-NI version	0.00
Processor package size	52.5 x 45.0 mm
Supported instruction sets	AVX 2.0
Intel Identity Protection Technology version	1.00
Intel® Small Business Advantage (Intel® SBA)	-
Power supply	700 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	445 mm
Width	169 mm
Height	432 mm
Weight	11000 g
