HP Z440 User Manual

Recovery using Windows 8 restore media
This recovery process requires Windows 8 restore discs, which can be ordered from the support website. The
Windows 8 restore media consists of a Windows 8 operating system disc and a Windows 8 driver disc.
For U.S. support, go to
http://www.hp.com/support. For worldwide support, go to http://www8.hp.com/us/
en/contact-hp/ww-contact-us.html. You can also order the media by calling support.
CAUTION: Using the Windows 8 operating system disc completely erases hard drive contents and reformats
the hard drive. All files that you have created and any software that you have installed on the workstation are
permanently removed. When reformatting is complete, the recovery process helps you restore the operating
system, as well as drivers.
Begin recovery using the Windows 8 operating system disc:
NOTE: It can take several minutes to load the operating system disc.
1. Back up all personal files.
2. Restart the workstation, and then follow the instructions provided with the Windows 8 operating
system disc to install the operating system.
3. When prompted, press any keyboard key.
NOTE: If the workstation does not boot to the DVD, restart the workstation and press Esc as the
workstation is starting to see the Startup menu. Use the arrow keys to select the boot menu, and then
press enter. Use the arrow keys to select the location where the recovery DVD is inserted to boot from
that device. Booting the DVD from UEFI Boot sources will result in a GPT boot partition. Booting from
Legacy Boot sources will result in an MBR boot partition. It is recommended that you boot Windows 8
from UEFI Boot sources to take full advantage of the features available in Windows 8.
4. Follow the on-screen instructions.
After the repair is completed and the Windows 8 desktop appears:
1. Remove the Windows 8 operating system disc, and then insert the driver disc.
NOTE: The driver disc will load prerequisite software, and then allow you to load drivers.
2. Install the Hardware Enabling Drivers first. HP recommends installing all available drivers.
3. You can download applications that come with the workstation at
http://www.hp.com.
32 Chapter 5 Setting up, backing up, restoring, and recovering Windows 8

HP Z440 Specifications

General

Tcase	66.2 °C
Bus type	QPI
Stepping	R2
FSB Parity	No
Processor cache	10 MB
Processor cores	4
Processor model	E5-1620V3
System bus rate	0 GT/s
Processor series	Intel Xeon E5-1600 v3
Processor socket	LGA 2011-v3
Processor threads	8
Processor codename	Haswell
Number of QPI links	0
Processor frequency	3.5 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.6 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	1x4, 1x8, 1x16
Thermal Design Power (TDP)	140 W
Number of processors installed	1
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	1333, 1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	68 GB/s
Maximum internal memory supported by processor	768 GB
Memory slots	8x DIMM
Internal memory	16 GB
Memory channels	Quad-channel
Memory clock speed	2133 MHz
Maximum internal memory	128 GB
Memory layout (slots x size)	2 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express
Storage media	SSD
Optical drive type	DVD Super Multi
Total storage capacity	256 GB
BD interface type	SATA
Discrete graphics card model	Not available
Recovery operating system	Windows 8.1 Pro
Operating system installed	Windows 7 Professional
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
PS/2 ports quantity	2
USB 2.0 ports quantity	5
Chassis type	Mini Tower
Product color	Black
Country of origin	China
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® C612
Scalability	1S
Processor code	SR20P
Processor ARK ID	82763
Intel TSX-NI version	0.00
Processor package size	52.5 x 45.0 mm
Supported instruction sets	AVX 2.0
Intel Identity Protection Technology version	1.00
Intel® Small Business Advantage (Intel® SBA)	-
Power supply	700 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	445 mm
Width	169 mm
Height	432 mm
Weight	11000 g
