Restoring SLED (preloaded systems only)
To restore SLED, you must use the SLED restore media. To create restore media:
1. Click the SUSE ISO icon on the desktop to go to the /iso folder. This folder contains all ISO images used
to preload your workstation.
2. Follow the instructions in the readme file in this folder to copy the ISO image file onto optical media.
3. Store the media in a safe place. If your workstation experiences a hard drive failure, use the ISO
recovery images to restore your operating system.
CAUTION: Restoring the operating system does not restore data. Back up your data using the method and
media of your choice.
Setting up Ubuntu
HP offers a 64-bit Ubuntu 14.04 LTS preload on some Z series Workstations and supports 64-bit Ubuntu
14.04 on other workstations.
Various versions of Ubuntu are certified and supported by Canonical on HP workstations. For more
information, go to the Ubuntu Desktop certified hardware search page at
http://www.ubuntu.com/
certification/desktop/make/HP/?category=Desktop and filter the list using the word “Workstation”.
Setting up preloaded Ubuntu
To set up Ubuntu on systems preloaded with the operating system:
1. Start the workstation.
The system boots and performs some setup activities in a non-interactive mode.
The system then reboots and plays a short video. After the video, an initial set of settings dialogs are
presented.
2. When prompted, enter the desired language and keyboard settings, time zone, first user name and
identity, and the user password.
NOTE: This initial user has privileges to become system administrator using the sudo command. There
is no user root in the typical Ubuntu installation.
After completion of the setup, the login screen appears.
3. Type the login information in the fields.
Using the HP Installer Kit Driver Disk
Ubuntu does not require registration to obtain software package updates. Updates can be obtained from
various “repositories” on the web using a variety of tools built into the OS. An internet connection and proxy
are all that may be required.
The HP Installer Kit for Linux driver disk for Ubuntu relies on the same mechanisms in order to satisfy
dependencies during installation. So the same internet access is needed, as well as capability to elevate from
the current user session to administrator privileges.
In some cases, HP-tested proprietary graphics drivers may be the only “payload” delivered by the driver disk.
46 Chapter 7 Setting up and restoring Linux

HP Z440 Specifications

General

Tcase	66.2 °C
Bus type	QPI
Stepping	R2
FSB Parity	No
Processor cache	10 MB
Processor cores	4
Processor model	E5-1620V3
System bus rate	0 GT/s
Processor series	Intel Xeon E5-1600 v3
Processor socket	LGA 2011-v3
Processor threads	8
Processor codename	Haswell
Number of QPI links	0
Processor frequency	3.5 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.6 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	1x4, 1x8, 1x16
Thermal Design Power (TDP)	140 W
Number of processors installed	1
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	1333, 1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	68 GB/s
Maximum internal memory supported by processor	768 GB
Memory slots	8x DIMM
Internal memory	16 GB
Memory channels	Quad-channel
Memory clock speed	2133 MHz
Maximum internal memory	128 GB
Memory layout (slots x size)	2 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express
Storage media	SSD
Optical drive type	DVD Super Multi
Total storage capacity	256 GB
BD interface type	SATA
Discrete graphics card model	Not available
Recovery operating system	Windows 8.1 Pro
Operating system installed	Windows 7 Professional
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
PS/2 ports quantity	2
USB 2.0 ports quantity	5
Chassis type	Mini Tower
Product color	Black
Country of origin	China
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® C612
Scalability	1S
Processor code	SR20P
Processor ARK ID	82763
Intel TSX-NI version	0.00
Processor package size	52.5 x 45.0 mm
Supported instruction sets	AVX 2.0
Intel Identity Protection Technology version	1.00
Intel® Small Business Advantage (Intel® SBA)	-
Power supply	700 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	445 mm
Width	169 mm
Height	432 mm
Weight	11000 g
