HP Z440 User Manual

System Recovery
CAUTION: This procedure will delete all user information. To prevent loss of information, be sure to back up
all user information so you can restore it after recovery.
Always use the System Restore procedure before you use the System Recovery program. See
System Restore
on page 22.
System Recovery completely erases and reformats the hard disk drive, deleting all data files that you have
created, and then reinstalls the operating system, programs, and drivers. However, you must reinstall any
software that was not installed on the workstation at the factory. This includes software that came on media
included in the workstation accessory box, and any software programs that you have installed.
You can order a recovery media set from support. For U.S. support, go to
http://www.hp.com/support. For
worldwide support, go to
http://www8.hp.com/us/en/contact-hp/ww-contact-us.html. You can also order
the recovery media set by calling support.
NOTE: Some features might not be available on systems that are shipped without a Windows operating
system.
You must choose one of the following methods to perform a System Recovery:
●
Recovery image — Run System Recovery from a recovery image stored on your hard disk drive. The
recovery image is a file that contains a copy of the original factory-shipped software. To perform a
System Recovery from a recovery image, see
System Recovery from a recovery partition image
on page 23.
●
Recovery media — Run System Recovery from recovery media that you have purchased separately.
System Recovery from a recovery partition image
CAUTION: System Recovery deletes all data and programs that you have created or installed.
A Windows system from the HP factory ships with a recovery partition. You can use the recovery partition to
recover the factory operating system.
1. Turn off the workstation. If necessary, press and hold the power button until the workstation turns off.
2. Disconnect all peripheral devices from the workstation except the monitor, keyboard, and mouse.
3. Press the power button to turn on the workstation.
4. As soon as you see the HP logo screen, repeatedly press the F11 key on your keyboard until the
Windows is Loading Files... message appears on the screen.
5. At the HP Recovery Manager screen, follow the on-screen instructions to continue.
6. When Windows has loaded, shut down the workstation, reconnect all peripheral devices, and then turn
the workstation back on.
Using HP Recovery Disc operating system discs
CAUTION: Using a Windows 7 operating system DVD completely erases hard drive contents and reformats
the hard drive. All files that you have created and any software that you have installed on the workstation are
permanently removed. When reformatting is complete, the recovery process helps you restore the operating
system, as well as the original drivers. Software that came with the system can be downloaded at
http://www.hp.com.
Use the steps provided in this section if you ordered a Windows 7 operating system DVD and Driver DVD.
Backing up, restoring, and recovering Windows 7 23

HP Z440 Specifications

General

Tcase	66.2 °C
Bus type	QPI
Stepping	R2
FSB Parity	No
Processor cache	10 MB
Processor cores	4
Processor model	E5-1620V3
System bus rate	0 GT/s
Processor series	Intel Xeon E5-1600 v3
Processor socket	LGA 2011-v3
Processor threads	8
Processor codename	Haswell
Number of QPI links	0
Processor frequency	3.5 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.6 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	1x4, 1x8, 1x16
Thermal Design Power (TDP)	140 W
Number of processors installed	1
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	1333, 1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	68 GB/s
Maximum internal memory supported by processor	768 GB
Memory slots	8x DIMM
Internal memory	16 GB
Memory channels	Quad-channel
Memory clock speed	2133 MHz
Maximum internal memory	128 GB
Memory layout (slots x size)	2 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express
Storage media	SSD
Optical drive type	DVD Super Multi
Total storage capacity	256 GB
BD interface type	SATA
Discrete graphics card model	Not available
Recovery operating system	Windows 8.1 Pro
Operating system installed	Windows 7 Professional
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
PS/2 ports quantity	2
USB 2.0 ports quantity	5
Chassis type	Mini Tower
Product color	Black
Country of origin	China
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® C612
Scalability	1S
Processor code	SR20P
Processor ARK ID	82763
Intel TSX-NI version	0.00
Processor package size	52.5 x 45.0 mm
Supported instruction sets	AVX 2.0
Intel Identity Protection Technology version	1.00
Intel® Small Business Advantage (Intel® SBA)	-
Power supply	700 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	445 mm
Width	169 mm
Height	432 mm
Weight	11000 g
