HP Z440 User Manual

◦
Use a different network cable to connect your workstation to the network.
◦
Connect a different workstation with a different cable to the network.
If your problem is not resolved, the network jack on your workstation or the network wall jack might be
faulty.
●
If you recently added new hardware, remove the hardware.
●
If you recently installed new software, uninstall the software.
●
Comprehensive online technical support is also available at
http://www.hp.com/support.
●
If the workstation will turn on but will not boot into the operating system, you may run the “pre-boot”
diagnostics utility, HP PC Hardware Diagnostics.
●
If the workstation will boot into the operating system, there are two possible tools that provide self-
solve diagnostics and online chat features (if internet access is also available).
◦
If you have HP Support Assistant, you may access it from the Start screen by clicking the HP
Support Assistant app, clicking My computer, and then clicking Diagnostics.
◦
If you do not have HP Support Assistant installed, you may access HP Instant Support Professional
Edition at
http://www.hp.com/go/ispe.
You may also access the Business Support Center (BSC) at
http://www.hp.com/go/bizsupport for the latest
online support information, software and drivers, for proactive notification, and access to a worldwide
community of peers and HP experts.
Comprehensive online technical support is also available at
http://www.hp.com/support.
If it becomes necessary to call for technical assistance, be prepared to do the following to ensure that your
service call is handled properly:
●
Be in front of your workstation when you call.
●
Before calling, write down the product ID number, workstation and monitor serial numbers, and the
failure ID produced by running the diagnostics if applicable.
●
Spend time troubleshooting the problem with the service technician.
●
Remove any hardware that was recently added to your system.
●
Remove any software that was recently installed.
NOTE: For sales information and warranty upgrades (HP Care Packs), call your local authorized service
provider or dealer.
Backing up, restoring, and recovering in Windows 10
This section provides information about the following processes. The information in the section is standard
procedure for most products.
●
Creating recovery media and backups
●
Restoring and recovering your system
For additional information, see Help and Support.
▲
Type help in the taskbar search box, and then select Help and Support.
If you encounter issues 37

HP Z440 Specifications

General

Tcase	66.2 °C
Bus type	QPI
Stepping	R2
FSB Parity	No
Processor cache	10 MB
Processor cores	4
Processor model	E5-1620V3
System bus rate	0 GT/s
Processor series	Intel Xeon E5-1600 v3
Processor socket	LGA 2011-v3
Processor threads	8
Processor codename	Haswell
Number of QPI links	0
Processor frequency	3.5 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.6 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	1x4, 1x8, 1x16
Thermal Design Power (TDP)	140 W
Number of processors installed	1
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	1333, 1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	68 GB/s
Maximum internal memory supported by processor	768 GB
Memory slots	8x DIMM
Internal memory	16 GB
Memory channels	Quad-channel
Memory clock speed	2133 MHz
Maximum internal memory	128 GB
Memory layout (slots x size)	2 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express
Storage media	SSD
Optical drive type	DVD Super Multi
Total storage capacity	256 GB
BD interface type	SATA
Discrete graphics card model	Not available
Recovery operating system	Windows 8.1 Pro
Operating system installed	Windows 7 Professional
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
PS/2 ports quantity	2
USB 2.0 ports quantity	5
Chassis type	Mini Tower
Product color	Black
Country of origin	China
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® C612
Scalability	1S
Processor code	SR20P
Processor ARK ID	82763
Intel TSX-NI version	0.00
Processor package size	52.5 x 45.0 mm
Supported instruction sets	AVX 2.0
Intel Identity Protection Technology version	1.00
Intel® Small Business Advantage (Intel® SBA)	-
Power supply	700 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	445 mm
Width	169 mm
Height	432 mm
Weight	11000 g
