Using a third-party graphics configuration utility
Third-party graphics cards may include a monitor configuration utility. Upon installation, this utility is
integrated into Windows. You can select the utility and use it to configure multiple monitors with your
workstation.
Refer to your graphics card documentation for details.
NOTE: Some third-party configuration utilities require that you enable the monitors in Windows before
using the configuration tool. Refer to your graphics card documentation for more information.
NOTE: Monitor configuration utilities are also often available on the HP support website.
Customizing the monitor display (Windows)
You can manually select or change the monitor model, refresh rates, screen resolution, color settings, font
sizes, and power management settings.
●
To change display settings in Windows 7, right-click a blank area on the desktop, and then click Screen
Resolution.
●
To change display settings in Windows 8, point to the upper-right or lower-right corner of the Start
screen to display the charms, and then click PC Settings > PC and Devices > Display.
●
For Windows 8, you can also change the display settings by pointing to the upper-right or lower-right
corner of the Start screen to display the Charms menu, and then clicking Search > Settings, typing
resolution in the Settings search field, and clicking Change the Screen Resolution.
●
To change display settings in Windows 10, type control panel in the taskbar search box, and then
select Control Panel. Select Appearance and Personalization, and then select Display.
For more information about customizing your monitor display, see the following resources:
●
Online documentation provided with the graphics controller utility
●
Documentation included with your monitor
Installing optional components
Depending on the workstation model, additional components (such as memory, hard drives, optical drives,
PCIe cards, or a second processor) can be installed on your workstation.
●
To view component installation videos, go to
http://www.hp.com/go/sml.
●
For installation guidelines and technical information, see the Maintenance and Service Guide for your
workstation at
http://www.hp.com/support/workstation_manuals.
Security
Some HP workstations have a lock on the side access panel. The key for this lock is shipped attached to the
back panel of the workstation chassis.
Additional security features reduce the risk of theft and alert when there has been a chassis intrusion. See
the Maintenance and Service Guide for your workstation at
http://www.hp.com/support/
workstation_manuals for information about additional hardware and software security features available for
your system.
18 Chapter 3 Setting up the workstation

HP Z440 Specifications

General

Tcase	66.2 °C
Bus type	QPI
Stepping	R2
FSB Parity	No
Processor cache	10 MB
Processor cores	4
Processor model	E5-1620V3
System bus rate	0 GT/s
Processor series	Intel Xeon E5-1600 v3
Processor socket	LGA 2011-v3
Processor threads	8
Processor codename	Haswell
Number of QPI links	0
Processor frequency	3.5 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.6 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	1x4, 1x8, 1x16
Thermal Design Power (TDP)	140 W
Number of processors installed	1
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	1333, 1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	68 GB/s
Maximum internal memory supported by processor	768 GB
Memory slots	8x DIMM
Internal memory	16 GB
Memory channels	Quad-channel
Memory clock speed	2133 MHz
Maximum internal memory	128 GB
Memory layout (slots x size)	2 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express
Storage media	SSD
Optical drive type	DVD Super Multi
Total storage capacity	256 GB
BD interface type	SATA
Discrete graphics card model	Not available
Recovery operating system	Windows 8.1 Pro
Operating system installed	Windows 7 Professional
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
PS/2 ports quantity	2
USB 2.0 ports quantity	5
Chassis type	Mini Tower
Product color	Black
Country of origin	China
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® C612
Scalability	1S
Processor code	SR20P
Processor ARK ID	82763
Intel TSX-NI version	0.00
Processor package size	52.5 x 45.0 mm
Supported instruction sets	AVX 2.0
Intel Identity Protection Technology version	1.00
Intel® Small Business Advantage (Intel® SBA)	-
Power supply	700 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	445 mm
Width	169 mm
Height	432 mm
Weight	11000 g
