HP Z440 User Manual

HPIKL driver disc
Recent versions of Red Hat Linux typically require only driver updates with minor fixes to support HP
workstations. These releases can usually be supported with the HPIKL driver disc, which can be used as a
post-installation utility for the standard Red Hat Linux install.
After you complete the standard Red Hat install and restart the system, a Red Hat first-boot utility runs. After
you specify a number of settings (such as the security level, time and date, ‘root’ password, and user
accounts), the utility lets you load an additional disc.
The driver disc is used during this phase. All content added by HP is in the /HP directory on the disc. You can
use it to build your own image or to browse the HP content.
Please see /HP directory on the disk for any last-minute README pointers for elements on the disk.
NOTE: Some installations may encounter problems if they are performed with a DisplayPort connection to
the monitor. This is because the default drivers that the OS installers use do not support DisplayPort
functionality. If you experience problems, try overriding the monitor choice for DisplayPort during the start of
the install and using the VESA driver instead. You can then set up the DisplayPort monitor later.
Installing with the HP Red Hat Linux driver disc
1. If you do not have the appropriate HP driver disc for a supported stream, create one (see HP Installer Kit
for Linux (HPIKL) on page 43.)
2. Install the operating system using the optical media included in the Red Hat Linux box-set.
3. If you have a Red Hat driver disk for the OS version you are installing, enter linux dd when the initial
install splash screen appears, and then press Enter.
4. When asked if you have a driver disc, select Yes. Place the Red Hat driver disc in the drive, and select the
appropriate drive:hd[abcd]. Continue the normal installation.
5. After successfully installing the operating system, reboot the workstation.
●
RHEL 6 or RHEL 7: Insert your HP driver disc. The HPIKL installation software automatically starts.
Follow the on-screen instructions to install the contents.
44 Chapter 7 Setting up and restoring Linux

HP Z440 Specifications

General

Tcase	66.2 °C
Bus type	QPI
Stepping	R2
FSB Parity	No
Processor cache	10 MB
Processor cores	4
Processor model	E5-1620V3
System bus rate	0 GT/s
Processor series	Intel Xeon E5-1600 v3
Processor socket	LGA 2011-v3
Processor threads	8
Processor codename	Haswell
Number of QPI links	0
Processor frequency	3.5 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.6 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	1x4, 1x8, 1x16
Thermal Design Power (TDP)	140 W
Number of processors installed	1
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	1333, 1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	68 GB/s
Maximum internal memory supported by processor	768 GB
Memory slots	8x DIMM
Internal memory	16 GB
Memory channels	Quad-channel
Memory clock speed	2133 MHz
Maximum internal memory	128 GB
Memory layout (slots x size)	2 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express
Storage media	SSD
Optical drive type	DVD Super Multi
Total storage capacity	256 GB
BD interface type	SATA
Discrete graphics card model	Not available
Recovery operating system	Windows 8.1 Pro
Operating system installed	Windows 7 Professional
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
PS/2 ports quantity	2
USB 2.0 ports quantity	5
Chassis type	Mini Tower
Product color	Black
Country of origin	China
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® C612
Scalability	1S
Processor code	SR20P
Processor ARK ID	82763
Intel TSX-NI version	0.00
Processor package size	52.5 x 45.0 mm
Supported instruction sets	AVX 2.0
Intel Identity Protection Technology version	1.00
Intel® Small Business Advantage (Intel® SBA)	-
Power supply	700 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	445 mm
Width	169 mm
Height	432 mm
Weight	11000 g
