HP Z440 User Manual

HP Installer Kit for Linux (HPIKL)
The HP Installer Kit for Linux helps users install certified versions of RHEL, SLED, or Ubuntu on HP
workstations. It is available as an operating system option on all HP workstations.
●
The kit contains tested drivers that augment and/or replace those found in RHEL, SLED, or Ubuntu, to
enable proper use and behavior on HP workstations.
●
The kit does not include the Linux operating system, which the user must supply. Commercial Linux
distributions are available for purchase from vendors such as Red Hat and SUSE. A variety of other Linux
distributions are available for free (e.g., Ubuntu). To view supported configurations and operating
systems, go to
http://www.hp.com/support/linux_hardware_matrix.
The HPIKL option may include a FreeDOS preload. This operating system option accommodates those who
have a customized Linux distribution or who have a licensed version of RHEL, SLED, or Ubuntu and would like
to install the HP-recommended driver additions.
The kit also can be downloaded using the following steps:
1. Go to
http://www.hp.com/support/workstation_swdrivers.
2. Select your workstation model.
3. Select the desired operating system.
4. Select your software/driver language, and then click the Software quick jump link.
5. Select the Obtain Software link for the appropriate package (typically the most recent revision).
6. Click I Accept to accept the terms of the license agreement.
7. Download the software ISO image and save it on a disc. This disk is your HP driver disc.
Setting up Red Hat Enterprise Linux
HP Z series Workstations are certified and supported on RHEL streams appropriate to the hardware
technology.
●
For details of RHEL support for a particular platform, see the Linux Hardware Matrix for HP Workstations
at
http://www.hp.com/support/linux_hardware_matrix.
●
For information about Red Hat certifications on HP workstations, go to
https://hardware.redhat.com.
HP Installer Kit for Linux (HPIKL) 43

HP Z440 Specifications

General

Tcase	66.2 °C
Bus type	QPI
Stepping	R2
FSB Parity	No
Processor cache	10 MB
Processor cores	4
Processor model	E5-1620V3
System bus rate	0 GT/s
Processor series	Intel Xeon E5-1600 v3
Processor socket	LGA 2011-v3
Processor threads	8
Processor codename	Haswell
Number of QPI links	0
Processor frequency	3.5 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.6 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	1x4, 1x8, 1x16
Thermal Design Power (TDP)	140 W
Number of processors installed	1
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	1333, 1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	68 GB/s
Maximum internal memory supported by processor	768 GB
Memory slots	8x DIMM
Internal memory	16 GB
Memory channels	Quad-channel
Memory clock speed	2133 MHz
Maximum internal memory	128 GB
Memory layout (slots x size)	2 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express
Storage media	SSD
Optical drive type	DVD Super Multi
Total storage capacity	256 GB
BD interface type	SATA
Discrete graphics card model	Not available
Recovery operating system	Windows 8.1 Pro
Operating system installed	Windows 7 Professional
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
PS/2 ports quantity	2
USB 2.0 ports quantity	5
Chassis type	Mini Tower
Product color	Black
Country of origin	China
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® C612
Scalability	1S
Processor code	SR20P
Processor ARK ID	82763
Intel TSX-NI version	0.00
Processor package size	52.5 x 45.0 mm
Supported instruction sets	AVX 2.0
Intel Identity Protection Technology version	1.00
Intel® Small Business Advantage (Intel® SBA)	-
Power supply	700 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	445 mm
Width	169 mm
Height	432 mm
Weight	11000 g
