HP Z440 User Manual

●
http://www.hp.com/go/workstationsupport—Provides technical support information for workstations.
●
http://www8.hp.com/us/en/contact-hp/phone-assist.html—Provides a listing of the worldwide
technical support telephone numbers. Select your region.
●
http://www.hp.com/support/workstation_swdrivers—Provides access to software and drivers for
workstations.
HP Support Center
To help you troubleshoot problems yourself, HP provides the HP Support Center. The HP Support Center is a
portal to an extensive selection of online tools. To access the HP Support Center, complete the following
steps:
1. Go to
http://www.hp.com/go/workstationsupport.
2. Search for your product.
3. In the Top issues & solutions tab, under Other solution options, select Troubleshoot a problem.
4. Select the problem that you are troubleshooting.
HP Chat Support
HP Chat Support is a set of web-based support tools that automate and speed up the resolution of problems
concerning desktop computing, tape storage, and printing.
HP Chat Support enables you to electronically submit a support ticket to HP over the web. When you submit a
support ticket, HP Chat Support collects information about the workstation and passes it to an online support
specialist. The collection of information might take up to 30 seconds, depending on the workstation
configuration. When you submit a support ticket, you receive a confirmation message containing your case
ID, the support hours for your location, and the estimated time of response.
For more information about HP Chat Support, go to
http://instantsupport.hp.com/.
NOTE: This feature is not available for Linux.
Customer Advisories, Customer and Security Bulletins, and Customer Notices
To find advisories, bulletins, and notices:
1. Go to
http://www.hp.com/go/workstationsupport.
2. Search for your product.
3. In the Top issues & solutions tab, under Other solution options, select Advisories, bulletins & notices.
4. Select an item for viewing.
Product Change Notifications
Product Change Notifications (PCNs) are proactive notifications for product changes occurring within a 30- to
60-day window of the effective date of the change in the manufacturing process. PCNs give customers
advance notice of changes to their product, such as an updated BIOS version that they might need to decide
whether to download prior to the change taking place. To view a list of PCNs, go to the Advisories, Bulletins
& Notices page for your product.
HP troubleshooting resources and tools 53

HP Z440 Specifications

General

Tcase	66.2 °C
Bus type	QPI
Stepping	R2
FSB Parity	No
Processor cache	10 MB
Processor cores	4
Processor model	E5-1620V3
System bus rate	0 GT/s
Processor series	Intel Xeon E5-1600 v3
Processor socket	LGA 2011-v3
Processor threads	8
Processor codename	Haswell
Number of QPI links	0
Processor frequency	3.5 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.6 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	1x4, 1x8, 1x16
Thermal Design Power (TDP)	140 W
Number of processors installed	1
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	1333, 1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	68 GB/s
Maximum internal memory supported by processor	768 GB
Memory slots	8x DIMM
Internal memory	16 GB
Memory channels	Quad-channel
Memory clock speed	2133 MHz
Maximum internal memory	128 GB
Memory layout (slots x size)	2 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express
Storage media	SSD
Optical drive type	DVD Super Multi
Total storage capacity	256 GB
BD interface type	SATA
Discrete graphics card model	Not available
Recovery operating system	Windows 8.1 Pro
Operating system installed	Windows 7 Professional
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
PS/2 ports quantity	2
USB 2.0 ports quantity	5
Chassis type	Mini Tower
Product color	Black
Country of origin	China
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® C612
Scalability	1S
Processor code	SR20P
Processor ARK ID	82763
Intel TSX-NI version	0.00
Processor package size	52.5 x 45.0 mm
Supported instruction sets	AVX 2.0
Intel Identity Protection Technology version	1.00
Intel® Small Business Advantage (Intel® SBA)	-
Power supply	700 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	445 mm
Width	169 mm
Height	432 mm
Weight	11000 g
