HP Z840 Workstation Series User Guide

HP Z840 Workstation rear panel components
1
Power supply Built-In Self-Test (BIST)
LED
8 USB 2.0 ports (2, black)
2
Rear power button 9 USB 3.0 ports (4, blue)
3
Serial connector (teal blue) 10
Network jacks (2, orange)
Bottom connector is AMT enabled
4
PS/2 keyboard connector (purple) 11 PCI/PCIe card slots
5
PS/2 mouse connector (light green) 12 Power cord connector
6
Audio line-out jack (green) 13 Security slot
7
Audio line-in jack (blue)
10 Chapter 2 Workstation features

HP Z840 Workstation Series Specifications

General

Chipset	Intel C612
Memory Slots	16 DIMM slots
Processor	Intel Xeon E5-2600 v3/v4 series
Storage	Supports SATA, SAS, and SSD
Graphics	NVIDIA Quadro and AMD FirePro options
Expansion Slots	7 PCIe slots
Power Supply	1125W 90% efficient
Operating System	Windows 10 Pro 64, Red Hat Enterprise Linux, SUSE Linux Enterprise Desktop
Ports	USB 3.0, USB 2.0
