HP Z840 Workstation Series Service Manual

HP Z440 Workstation rear panel components
1
Power supply Built-In Self-Test
(BIST) LED
8 Audio line-out jack (light green)
2
Rear power button and LED 9 Audio line-in jack (blue)
3
PS/2 keyboard connector (purple) 10 PCI/PCIe card slots
4
PS/2 mouse connector (green) 11 Power cord connector
5
USB 2.0 ports (2, black) 12 Universal chassis clamp opening
6
USB 3.0 ports (4, blue) 13 Padlock loop
7
AMT-enabled RJ-45 (network) jack
(orange)
14 Security slot
HP Z440 Workstation components 3

HP Z840 Workstation Series Specifications

General

Chipset	Intel C612
Memory Slots	16 DIMM slots
Processor	Intel Xeon E5-2600 v3/v4 series
Storage	Supports SATA, SAS, and SSD
Graphics	NVIDIA Quadro and AMD FirePro options
Expansion Slots	7 PCIe slots
Power Supply	1125W 90% efficient
Operating System	Windows 10 Pro 64, Red Hat Enterprise Linux, SUSE Linux Enterprise Desktop
Ports	USB 3.0, USB 2.0
