HP Z840 Workstation Series Service Manual

HP Z440 Workstation chassis components
1 Fan 10 System board
2 Hard drive carrier 11 Rear system fan and holder
3 Hard drive, 3.5-inch 12 Chassis
4 Side access panel 13 Speaker
5 Memory fans 14 PCIe card
6 Heat sink 15 Front bay filler (optional)
7 Processor 16 Optical drive, slim
8 Memory module (DIMM) 17 Front bezel
9 Power supply
4 Chapter 1 Hardware overview

HP Z840 Workstation Series Specifications

General

Chipset	Intel C612
Memory Slots	16 DIMM slots
Processor	Intel Xeon E5-2600 v3/v4 series
Storage	Supports SATA, SAS, and SSD
Graphics	NVIDIA Quadro and AMD FirePro options
Expansion Slots	7 PCIe slots
Power Supply	1125W 90% efficient
Operating System	Windows 10 Pro 64, Red Hat Enterprise Linux, SUSE Linux Enterprise Desktop
Ports	USB 3.0, USB 2.0
