HP Z840 Workstation Series Service Manual

HP Z440 Workstation system board components
I/O PCI/PCIe Power Security
1 Front audio 13 PCIe2 x1 23 Battery 31 Chassis intrusion sensor
2 Front USB 3.0 14 PCIe3 x16 24 Processor and memory
power
32 Chassis solenoid lock
3 Internal USB 2.0 15 PCIe2 x4 25 Front UI/power button/
LED
Service
4 Internal USB 3.0 16 PCIe3 x8 26 Main power 33 Boot Block Recovery (BBR)
jumper
5 Keyboard/mouse 17 PCIe3 x16 27 Rear power button/LED 34 Clear CMOS button
6 Network 18 PCI 32/33 SATA (SAS Optional) 35 ME/AMT flash override
7 Rear audio Cooling 28 Hard drive LED 36 Password jumper
8 Rear USB 2.0 19 CPU0 fan 29 SATA 6 Gb/s
9 Rear USB 3.0 20 Front fan 30 sSATA 6 Gb/s
10 Serial (optional) 21 Memory fans
11 Speaker 22 Rear fan
12
Thunderbolt
TM
GPIO
NOTE: For related expansion card slot information, see
Expansion slots on page 51
HP Z440 Workstation components 5

HP Z840 Workstation Series Specifications

General

Chipset	Intel C612
Memory Slots	16 DIMM slots
Processor	Intel Xeon E5-2600 v3/v4 series
Storage	Supports SATA, SAS, and SSD
Graphics	NVIDIA Quadro and AMD FirePro options
Expansion Slots	7 PCIe slots
Power Supply	1125W 90% efficient
Operating System	Windows 10 Pro 64, Red Hat Enterprise Linux, SUSE Linux Enterprise Desktop
Ports	USB 3.0, USB 2.0
