HP Z840 Workstation Series Service Manual

System cabling
HP Z440 Workstation system cabling
See
HP Z440 Workstation system board components on page 5 to determine the location of system board
connectors.
Cable To Cable designator on system board
PSU cable PCA (Main PWR) P1
PSU cable PCA (PWR MEM) P2
PSU cable First hard drive (Bay 6) D1
PSU cable Second hard drive (Bay 5) D2
PSU cable Third hard drive (Bay 4) D3
PSU cable First optical drive (Bay 1) D4
PSU cable Second optical drive (Bay 2) D5
PSU cable Other drive (Bay 3) D6
PSU cable First graphics card G1 (600 W PSU only)
Speaker PCA P6 (SPKR) white
Cooler fan cable PCA P8 (CPU0 FAN) white
System fan cable PCA P95 (REAR FAN) white
Memory fan cable PCAx P92 (MEM FAN) white
Front audio cable * PCA P28 (FRONT AUD) black
Front 1394 cable PCA J12 1394,White
LED/Power button cable PCA P5 (PB/LED) black
Front USB 3.0 cable PCA P29 (USB 3.0) blue
Front USB 2.0 cable PCA P27 (FRONT USB 2.0) yellow
Media card reader PCA P24 (USB2) blue
Front fan cable PCA P9 (FRNTFAN) white
Second serial port PCA P52 (COM) black
Chassis solenoid lock PCA P124 (SOL_LOCK) black
Chassis Intrusion Sender PCA P125 (I_SENSE) white
* If an audio card is installed, connect the front audio cable to the audio card connector.
Component replacement guidelines 73

HP Z840 Workstation Series Specifications

General

Chipset	Intel C612
Memory Slots	16 DIMM slots
Processor	Intel Xeon E5-2600 v3/v4 series
Storage	Supports SATA, SAS, and SSD
Graphics	NVIDIA Quadro and AMD FirePro options
Expansion Slots	7 PCIe slots
Power Supply	1125W 90% efficient
Operating System	Windows 10 Pro 64, Red Hat Enterprise Linux, SUSE Linux Enterprise Desktop
Ports	USB 3.0, USB 2.0
