HP Z840 Workstation Series Service Manual

HP Z640 Workstation components
For complete and current information on supported accessories and components for the computer, see
http://partsurfer.hp.com.
●
HP Z640 Workstation front panel components
●
HP Z640 Workstation rear panel components
●
HP Z640 Workstation chassis components
●
HP Z640 Workstation system board components
●
HP Z640 Workstation system board architecture
●
HP Z640 Workstation system board riser architecture
●
HP Z640 Workstation specifications
HP Z640 Workstation front panel components
1 External drive bays 5 USB 3.0 charging port
2 Optical drive 6
USB 3.0 ports (3)
3
Power button and LED 7
Audio-out (headphone)/Audio-in
(microphone) combo jack
4
Hard drive activity light 8 Microphone jack
8 Chapter 1 Hardware overview

HP Z840 Workstation Series Specifications

General

Chipset	Intel C612
Memory Slots	16 DIMM slots
Processor	Intel Xeon E5-2600 v3/v4 series
Storage	Supports SATA, SAS, and SSD
Graphics	NVIDIA Quadro and AMD FirePro options
Expansion Slots	7 PCIe slots
Power Supply	1125W 90% efficient
Operating System	Windows 10 Pro 64, Red Hat Enterprise Linux, SUSE Linux Enterprise Desktop
Ports	USB 3.0, USB 2.0
