HP Z840 Workstation Series

●
Error checking and correcting (ECC)-protected
●
Four direct-attach memory channels enable low-latency access and fast data transfer for
improved performance
●
Up to 128 GB system memory (16 GB DIMMs)
●
2133 MHz 4, 8, 16 GB ECC Registered DIMMs
NOTE: Only ECC DIMMs are supported.
NOTE: Distribute DIMMs across all memory channels for optimal performance.
Graphics cards
Supports:
●
PCIe Gen3 (PCIe3) bus speeds; can support two PCIe Gen3 graphics cards in PCIe3 x16 slots
●
Up to 225 W graphics or compute card in the primary graphics slot (700 W PSU)
●
Up to 75 W graphics in primary slot (525 W PSU)
●
A second graphics card in the second PCIe3 x16 slot
●
Third and fourth 2D graphics cards in additional PCIe2 slots
●
Combined power consumption of all cards not to exceed 335 W (subject to overall system
power limitations and configuration restrictions) (700 W PSU)
●
Combined power consumption of all cards not to exceed 140 W (subject to overall system
power limitations and configuration restrictions) (525 W PSU)
I/O technology
●
SATA RAID 0/1/5/10 on sSATA
●
Six SATA/AHCI ports (2 SATA 6 Gb/s, 4 sSATA 6Gb/s)
●
Two ports capable of optional eSATA. eSATA capable with optional dual eSATA bulkhead
kit.
●
Eight external USB 3.0 ports (4 front, 4 rear)
●
Two external USB 2.0 ports (2 rear)
●
Two internal USB 2.0 ports
●
One internal USB 3.0 port
●
Serial Attached SCSI (SAS) drives supported with 9217-4i4e plug-in card
Weight
●
Standard configuration: 13.7 kg (30.2 lb)
●
Minimum configuration: 11.0 kg (24.3 lb)
●
Maximum configuration: 17.7 kg (39.4 lb)
Chassis dimensions
Tower configuration:
●
Height: 43.18 cm (17.00 in)
●
Width: 16.89 cm (6.65 in)
●
Depth: 44.45 cm (17.50 in)
Desktop configuration:
●
Height: 16.89 cm (6.65 in)
●
Width: 43.18 cm (17.00 in)
●
Depth: 44.45 cm (17.50 in)
HP Z440 Workstation components 7
