HP Z840 Workstation Series Service Manual

HP Z440 Workstation installation sequence recommendations
Load
order
Card description Slot 1 Slot 2 Slot 3 Slot 4 Slot 5 Slot 6
1 First PCIe graphic card Only
2
Second PCIe graphic card or
Tesla C2075
Only
3 Third PCIe graphic card Only
4 Fourth PCIe graphic card Only
5 SAS card 2nd 1st 3rd
6 Z Turbo Drive 1st 3rd 1st 2nd
7 Z Turbo Drive 2nd 2nd 1st
8 PCIe 1394b card 1st 2nd
9 PCIe audio card 1st 2nd 3rd 4th
10 PCIe NIC card (LAN) 1st 2nd 3rd 4th
11 e-SATA bulkhead kit 2nd 3rd 1st
12 Second serial port kit 2nd 3rd 1st
NOTE: Slot sequenced from the rear I/O aperture to the board edge.
Component replacement guidelines 53

HP Z840 Workstation Series Specifications

General

Chipset	Intel C612
Memory Slots	16 DIMM slots
Processor	Intel Xeon E5-2600 v3/v4 series
Storage	Supports SATA, SAS, and SSD
Graphics	NVIDIA Quadro and AMD FirePro options
Expansion Slots	7 PCIe slots
Power Supply	1125W 90% efficient
Operating System	Windows 10 Pro 64, Red Hat Enterprise Linux, SUSE Linux Enterprise Desktop
Ports	USB 3.0, USB 2.0
