3) Tighten the Wing Nut and flip the
Shoulder Gauge down before continuing.
Fig. 4. Wing Nut and Top Jaw of vise removed to show top view of the Bottom Jaw only, for key
positioning.
4) Make sure the key is lying flat
against the back of the Bottom Jaw
before tightening the Wing Nut.
20
