CodeMax
®
66
# Description Stock #
1. Keypad MAX-4
2. Pad Locator MAX-5
3. Keypad Display Circuit Board MAX-6
4. Pivot Arm Assembly CM-1024X
5. Cutter Head Assembly CM-1053X
6. Grip Spring CM-1079
7. Belt Guard CM-1014B
8. Angle Index Pin CM-1042
9. Belt CM-1083MA
10. Motor Pulley CM-1060MA
11. Set Screw 9100-11
12. Nut CM-50148
13. Screw CM-50158
14. Motor Mounting Bracket CM-1040MA
15. Hex Nut CM-50157
16. Screw CM-50167
17. Motor CM-1080MA
18. Pivot Pin CM-1043
19. Washer CM-50100
20. Power Cord MAX-34
21. Screw MAX-35
22. Plunger U-Bracket MAX-43
23. Display Board Wire Assembly MAX-44
24. Screw #8-32 x 1/4 MAX-46
25. Gasket MAX-47
26. Rubber Bumper CM-50133MA
27. Screw CM-50134
28. Amp Fuse MAX-78
29. Washer CM-50167-1
30. Motor Support CM-50186
31. Motor Support Screws (2) CM-50188
Circuit Connections
A1 connects to: A
B1 connects to: B
C1 connects to: C
D1 connects to: D
E1 connects to: E
F1 connects to: F
G1 connects to: G
H1 connects to: H
J1 connects to: J
CodeMax
®
Parts List
