9. Exploded Views
Pivot Arm With Safety Switch Assembly
64
CodeMax
®
CodeMax
®
# Description Stock #
1. Easy Grip Wing Nut EGN-1
2. Ball Bearing Washer BBW-2
3. Top Jaw CM-1056MA
4. Spring CM-1293MA
5. Stud CM-1019MA
6. Ball Bearing CM-50108
7. Set Screw CM-50110
8. Bottom Jaw (factory installation recommended) CM-1055MA
9. Tip Stop CM-1054MA
10. Spring CM-1090MA
11. Set Screw CM-50139
12. Eccentric Shaft CM-1041
13. Set Screw CM-50109
14. Set Screw CM-50112
15. & 16 Turn Bar & Shoulder Gauge CMB-FG
17. Retaining Ring CM-50105
18. 2-56 Screw MAX-92
19. Shoulder Gauge Wire Assembly MAX-90
20. Shoulder Gauge Micro Switch Bracket MAX-91
21. 6-32 Set Screw MAX-89
