Fig. 2
10) Swing the key Shoulder Gauge down to release the Turn Bar. Then, firmly gripping the
right end of the Turn Bar so that it remains stationary, swing the key Shoulder Gauge up
against the key. Rotate the Turn Bar to the desired position and hold it there. The Shoulder
Gauge should just touch the shoulder of the key (see Fig. 2). Now, without rotating
the Turn Bar any more, tighten the set screw that holds the Turn Bar.
58
CodeMax
®
CodeMax
®
Rotate Turn
Bar
Swing Shoulder
Gauge
