Item Description Status
1 Power On/Standby button and system power
LED (Server 1)
1
Solid green = System on
Flashing green = Performing power on
sequence Solid amber = System in standby
Off = No power present
2
2 Power On/Standby button and system power
LED (Server 2)
Solid green = System on
Flashing green = Performing power on
sequence Solid amber = System in standby
Off = No power present
2
3 Health LED (Server 2)
1
Solid green = Normal
Flashing amber = System degraded
Flashing red = System critical
3
4 Health LED (Server 1)
1
Solid green = Normal
Flashing amber = System degraded
Flashing red = System critical
3
5 Health LED (Server 3)
1
Solid green = Normal
Flashing amber = System degraded
Flashing red = System critical
3
6 Health LED (Server 4)
1
Solid green = Normal
Flashing amber = System degraded
Flashing red = System critical
3
7 Power On/Standby button and system power
LED (Server 4)
1
Solid green = System on
Flashing green = Performing power on
sequence Solid amber = System in standby
Off = No power present
2
Table Continued
Identifying components and LEDs 15
