HPE Apollo 2000 Gen10

HPE Apollo r2800 Gen10 Chassis
Cable color Description
Orange r2600/r2800 Gen10 Chassis power cable for server 1 and server 2
Blue Chassis power cable for hot-plug drives
Amber Chassis power cable for server 3 and server 4
Pink Chassis pass-through power supply cable
Fan power cabling
Cable color Description
Orange Fan power cable assembly for fans 1, 2, 5, and 6
Blue Fan power cable assembly for fans 3, 4, 7, and 8
64 Fan power cabling
