ItemItem DescriptionDescription
1 DIMM slots
2 Ambient temperature sensor connector
3 M.2 slot
4 SimSAS x4 port
5 Storage controller backup power connector
6 System board: System power connector
7 Fan connector
8 PDB: System power connector
9 Drive power connector
10 PDB: 4-pin processor power connector
11 Slot 2 PCIe4 x8 (4, 1), supports up to 25W
12 System maintenance switch
13 System battery
14 Slot 1 PCIe5 x16 (16, 8, 4, 1), supports up to 25W
15 System board: 4-pin processor power connector
This M.2 slot does not support direct SSD installation. This slot instead supports the iLO-M.2 serial module option, which supports
NVMe SSDs.
This connector supports a maximum of four SATA devices.
SubtopicsSubtopics
System maintenance switch descriptionsSystem maintenance switch descriptions
DIMM label identificationDIMM label identification
DIMM slot numberingDIMM slot numbering
