Page #77 background imageLoading...
Page #77 background image
Chapter 6 Function Introduction Shenzhen Hpmont Technology Co., Ltd.
66 HD3L Series Controller User Manual
6.2.15 F17: Fault Protect Parameters
Motor overheat fault (F17.00 - F17.02)
Ref. Code Function Description Setting Range [Default]
F17.00 Input voltage at motor overheat 0.00 - 10.00 [0.00V]
F17.01 Thermistor type 0 - 2 [0]
0: Not detect the motor overheat (NC).
1: Positive charateristic (PTC).
When AI4 input exceeds F17.00, HD3L alarms E0020 fault (motor overheat).
2: Negative charateristic (NTC).
When AI4 input is less than F17.00, HD3L alarms E0020 fault (motor overheat).
Note: Only when correctly set CN2 and CN3 of I/O board can do the motor overheat detection.
F17.02 Threshold resistance at motor overheat 0.0 - 10.0 [5.0kΩ]
Input and output voltage phase loss fault (F17.03 - F17.06)
Ref. Code Function Description Setting Range [Default]
F17.03 The detection base of lack of input 0 - 100 [30%]
F17.04 The detection time of lack of input 0.0 - 5.0 [1.0s]
F17.03 is a percentage of HD3Ls rated voltage.
When HD3L detects certain input voltage does not hit the detect base (F17.03) and exceeds the detect time
(F17.04), HD3L alarms E0015 fault (lack of input).
F17.03 or F17.04 = 0 or in the battery driven run mode, HD3L will not detect Input voltage phase loss
fault.
F17.05 The detection base of lack of output 0 - 100 [20%]
F17.06 The detection time of lack of output 0.0 - 20.0 [3.0s]
F17.05 value is a percentage of HD3Ls rated current.
When HD3L detects certain output current does not hit the detect base (F17.05) and exceeds the detect
time (F17.06), HD3L alarms E0016 fault (lack of output).
F17.05 or F17.06 = 0, HD3L will not detect output voltage phase loss fault.
Motor fault (F17.07)
Ref. Code Function Description Setting Range [Default]
F17.07 Motor overload protect factor 20.0 - 110.0 [100.0%]
The motor overload protection factor can be set as 100% when HD3L drives a motor of the same power
class.
To protect the motor when the motor power is smaller than the standard matched power, user needs to set
proper motor overload protection factor (F17.07). The factor can derive from the following formula:
Motor overload protect factor
󰇛
F17.07
󰇜
Rated current of motor󰇛F07.02󰇜
Rated output current of HD3L
100%
