Appendix A Parameter Shenzhen Hpmont Technology Co., Ltd.
86 HD3L Series Controller User Manual
Ref. Code
Function
Setting Range Default
Unit
Attribute Setting
Bit13: Stop signal
Bit14,Bit15: Unused
d01: Drive Status Parameters, on pages 43 -44
d01.00 Control mode 0 - 5 Actual *
d01.01 Setting speed (m/s) 0.000 - 9.999 Actual *
d01.02
Setting speed (after Acc /
Dec) (m/s)
0.000 - 9.999 Actual *
d01.03 Feedback speed (m/s) 0.000 - 9.999 Actual *
d01.04 Setting frequency (Hz) 0.01 - 100.00Hz Actual *
d01.05
Setting frequency (after Acc /
Dec)
0.01 - 100.00Hz Actual *
d01.06 Output frequency 0.01 - 100.00Hz Actual *
d01.07 Setting RPM 0 - 24000RPM Actual *
d01.08 Running RPM 0 - 24000RPM Actual *
d01.09 Unused
d01.10 Output voltage 0 - 999V Actual *
d01.11 Output current 0.1 - 999.9A Actual *
d01.12 Output torque
0.0 - 300.0% (motor rated
torque)
Actual *
d01.13 Output power
0.0 - 200.0% (motor rated
power)
Actual *
d01.14 DC bus voltage 0 - 999V Actual *
d01.15 - d01.16 Unused
d02: Analogue Status Display Parameters, on pages 44 - 45
d02.00 AI1 voltage 0.00 -10.00V Actual *
d02.01 AI1 voltage (after calculating) 0.00 -10.00V Actual *
d02.02 AI2 voltage 0.00 -10.00V Actual *
d02.03 AI2 voltage (after calculating) 0.00 -10.00V Actual *
d02.04 AI3 voltage 0.00 -10.00V Actual *
d02.05 AI3 voltage (after calculating) 0.00 -10.00V Actual *
d02.06 AI4 voltage 0.00 -10.00V Actual *
d02.07 AI4 voltage (after calculating) 0.00 -10.00V Actual *
d02.08 AO1 output 0.00 -10.00V Actual *
d02.09 AO2 output 0.00 -10.00V Actual *
d03: Running Status Parameters, on pages 45 - 46
d03.00 Heatsink temperature 0.0 - 999.9
Actual *
d03.01 Input terminal status
Display in 16-bit binary:
Bit15 - Bit12 Unused
Bit11 - Bit0 correspond to DI12 -
DI1
0: Disconnects with common
terminal
Actual *
