Chapter 7 Elevator Application Guidance Shenzhen Hpmont Technology Co., Ltd
―92― HD5L Series Controller User Manual
Note:
1. During step 2 and step 3, it need manually open the run contactor.
2. If the system has synchronous motor radial contactor, the short-circuit signal of radial contactor
should be removed. Otherwise it will cause over-current fault.
3. If the system is power off before finish the step6, you should restart auto-tuning.
7.1.4 Inspection Running
Before inspection running
Make sure the follow steps:
1. After motor parameter auto-tuning, motor output U/V/W connections and encoder connection
are not changed.
2. Set F03.06 (inspection Acc speed) and F03.07 (inspection Dec speed).
Inspection running
1. If the actual motor running direction is not the command direction, you can change the value of
F00.08 (run direction).
2. Carefully make sure that the motor can run normally.
3. Make sure the motor can run normally and the signals of the brake and power circuit etc. can
act normally, then it will run fast.
7.1.5 Run Fast
1. Give the normal floor run command so that to the elevator can run normally. Then set Group
F02 of start & stop parameters, start stopping parameters, adjust starting & stopping brake and
motor running time sequence to make sure that the elevator does not shake at start & stop.
• For the asynchronous motor, adjust Group F02 to avoid obviously shaking at start &stop.
• For the synchronous motor, it also need set Group F06 to avoid elevator brake at start.
• If the synchronous motor has SINCOS encoder, it can achieve elevator smooth start using
weigh less method (Group F06). And F02.02 (Retention time of start zero-speed) is set at
least as 0.5s.
2. If the elevator has slight shake at running, please properly adjust Group F08.
3. To adjust leveling precision, terminal MS control (F00.05 = 2) can adjust Acc/Dec curve (Group
F03) to unify level and adjust F03.13 (stop Dec jerk) to make leveling precision.
