Shenzhen Hpmont Technology Co., Ltd Chapter 7 Elevator Application Guidance
HD5L Series Controller User Manual ―97―
7.3.2 Set Parameter
Refer to Table 7-1 for the general function code.
The terminal analogue special function code setting content is shown as Table 7-3.
Table 7-3 Terminal analogue run special function code
Code Name Recommended value Remark
F00.05 Operating mode 1 Terminal analogue control.
F02.02 Retention time of start zero-speed 0.5s According the situation of running
contactor and brake at motor
start& stop to adjust.
F02.06 Retention time of stop zero-speed 0.5s
F03.00 Acceleration speed 0.700m/s
2
If the controller can not fast-track
speed command of the elevator
controller, please add more the
values of F03.00－F03.05.
F03.01 Start Acc jerk 0.350m/s
3
F03.02 End Acc jerk 0.600m/s
3
F03.03 Deceleration speed 0.700m/s
2
F03.04 Start Dec jerk 0.600m/s
3
F03.05 End Dec jerk 0.350m/s
3
F06.00 Pre-torque selection 1 Analogue weighing feedback.
F06.01 Up pre-torque bias 50.0%
Set according to actual situation
and debug according to running
effect.
F06.02 Down pre-torque bias 50.0%
F06.03 Up electrical pre-torque gain 1.000
F06.04 Up brake pre-torque gain 1.000
F06.05 Down electrical pre-torque gain 1.000
F06.06 Down brake pre-torque gain 1.000
F12.01 DI1 terminal function 1 Controller enabled (EN)
F12.02 DI2 terminal function 2 UP
F12.03 DI3 terminal function 3 DN
F12.15 DO1 terminal function 2 Controller is running
F12.16 DO2 terminal function 3
Controller is at zero-speed
running
F12.17 RLY1 terminal function 14 Controller fault
F13.00 AI1 function 1 Speed setting
F13.01 AI2 function 2 Weighing signal
F13.04 AI1 bias 0.0%
Adjust according to actual
situation
F13.05 AI1 gain 1.00
F13.06 AI1 filter time 0.05s
F13.07 AI2 bias 0.0%
F13.08 AI2 gain 1.00
F13.09 AI2 filter time 0.05s
7
