Shenzhen Hpmont Technology Co., Ltd Chapter 6 Function Introduction
HD5L Series Controller User Manual ―59―
6.2 Group F: General Function Parameters
6.2.1 Group F00 Basic Parameters
Code Name Description Range
factory setting
F00.00 Motor type 0,1
0
0: Asynchronous motor.
1: Synchronous motor.
F00.01 Control mode 0
2
2
0: V/f control. Constant voltage/frequency ratio control.
• It is applicable for special elevator occasion. This mode does not need the encoder and its
control effect is not so good as the vector control.
• When select V/f control, please properly set the V/f control parameter of Group F07 to achieve
proper efficiency.
1: SVC control. Sensorless vector control. It is only applicable for the asynchronous motor.
2: Closed-loop vector control. Sensor vector control.
• Closed-loop vector and applicable for elevator high accuracy of speed control. In generally the
elevator will take this mode.
Note:
1. V/f and SVC control are applicable for the motor without installing encoder which are one
temporary running mode when the elevator is in inspection running.
2. When select SVC or closed-loop vector control mode, you should do motor parameter
auto-tuning.
Auto-tuning process: Correctly set the motor nameplate parameters (F07.00
F07.04 / F10.00
F10.05), then start the motor parameter auto-tuning to obtain the right parameters.
Meanwhile set vector control parameters of Group F08 to achieve excellent vector control
efficiency.
F00.02 Elevator rated speed 0.100
4.000
1.500m/s
The elevator nominal rated speed.
• All speed setting value in the function parameters must not exceed this value.
F00.03 Controller max output frequency 5.00
100.00
50.00Hz
It defines the maximum frequency that the controller is allowed to output.
• It should be careful to set reasonable parameters according to the nameplate of the motor and the
actual operating conditions.
F00.04 Traction machine mechanical parameters 10.0
6000.0
60.0
It defines the relationship between the elevator speed and the motor rotation speed.
• The traction machine mechanical parameters are calculated based on the traction machine
parameters. They determine the control precision and must be correctly set.
The elevator speed and motor rotation speed relationship is shown below:
Elevator speed (m s
⁄
) =
Motor rotation speed (rpm)
60
×
F00.04
1000
The formula for calculating motor mechanical parameters is as below:
F00.04 =
π × D
i × Winding mode
D: Diameter of motor (mm);
i: Dec. rate;
Winding mode: The way that the hoist cable is wound, set according to the actual elevator setting.
6
