Chapter 2 Product Information Shenzhen Hpmont Technology Co., Ltd
―4― HD5L Series Controller User Manual
2.3 Specifications
Item Specification
Electrical
Rated voltage and
frequency
Single-phase: 200－240V, 50/60Hz
Three-phase: 380－460V, 50/60Hz
Accuracy
Voltage: fluctuation within ± 10%, imbalance rate < 3%
Frequency: ± 5%
Output voltage 0－input voltage
Output frequency 0－100.00Hz
Performance
Maximum current
150% rated output current for 2 minutes
180% rated output current for 10 seconds
Control mode
V/f control; Open-loop vector control (SVC);
Closed-loop vector control (VC)
Operation command
control mode
Panel control; external terminal control; host computer communication
control via SCI communication port
Speed setting mode Digital setting, analogue setting, SCI communication setting
Speed setting
resolution
Digital setting: 0.01Hz
Analogue setting: 0.1% × max-frequency
Speed control accuracy SVC: ± 0.5% VC: ± 0.05%
Speed control range SVC: 1:100 VC: 1:1000
Torque control
response
SVC: < 200ms VC: < 50ms
Start torque SVC: 180% rated-torque /0.5Hz VC: 200% rated-torque /0Hz
Characteristic
Parameter upload and
download function
To achieve parameters uploading or downloading
Programmable I/O
interface
The programmable input interface has up to 34 functions
The pragrammable output interface has up to 19 functions
Communication
protocol
Controller is built-in MODBUS communication protocol
Protection
Auto-inspection
To eliminate the potential safety problems, safety inspection for the
peripheral devices is provided when power is on
Over-speed protection To make sure safe running, elevator over-speed protection is provided
Speed deviation
protection
To eliminate the potential safety problems, speed deviation detection
protection is provided
Up/down forced
deceleration function
Up/down forced deceleration function, to avoid climbing elevator or plunging
elevator
I/O phase loss
protection
I/O phase loss auto-detect and alarm function
Motor temperature
detection
Real time detection for the motor temperature
Power output
grounding fault
protection
Power output grounding fault protection is enabled
Power output short
circuit protection
Power output short circuit protection is enabled
