Chapter 7 Elevator Application Guidance Shenzhen Hpmont Technology Co., Ltd
―94― HD5L Series Controller User Manual
7.2.2 Set Parameter
The terminal MS general function code setting content is shown as Table 7-1 and special function
code setting content is shown as Table 7-2.
Table 7-1 General function code setting table
Code Name Recommended value Remark
F00.00 Motor type Depend on actual value
F00.01 Control mode Depend on actual value
F00.02 Elevator rated speed Depend on actual value
F00.03 Max output freqency Depend on actual value
F00.04
Traction machine mechanical
parameters
Depend on actual
calculate value
F07.00 / F10.01 Motor rated power Depend on actual value
Motor nameplate
parameters.
F07.01 / F10.02 Motor rated voltage Depend on actual value
F07.02 / F10.03 Motor rated current Depend on actual value
F07.03 / F10.04 Motor rated frequency Depend on actual value
F07.04 / F10.05 Motor rated rpm Depend on actual value
F08.00 ASR proportional gain 1 500
Adjust according to
running effect.
Generally use the
default value.
F08.01 ASR integral coefficient 1 500
F08.02 ASR proportional gain 2 500
F08.03 ASR integral coefficient 2 500
F08.04 ASR swithcing frequency 1 10.00Hz
F08.05 ASR swithcing frequency 2 15.00Hz
F08.09 UP electrical torque limitation 180.0%
Adjust according to
running effect.
Generally use the
default value.
F08.10 DN electrical torque limitation 180.0%
F08.11 UP regenerative torque limitation 180.0%
F08.12 DN regenerative torque limitation 180.0%
F11.00 HD5L PG card Depend on actual value
F11.01 PG P/R Depend on actual value
F11.02 PG direction setting Depend on actual value
