Shenzhen Hpmont Technology Co., Ltd Chapter 6 Function Introduction
HD5L Series Controller User Manual ―83―
Fault auto-reset function and fault relay action (F17.08
F17.10)
Auto reset function enables the controller to reset the fault as per the preset times (F17.08) and
interval (F17.09).
The following faults do not have the auto reset function:
E0008: Power module faulty E0021: Control board EEPROM faulty
E0010: Brake unit faulty E0023: Parameter setting faulty
E0013: Soft start failed E0024: External faulty
E0014: Current detect faulty E0036: Contactor faulty
Code Name Description Range
factory setting
F17.09 Fault auto reset interval 2.0
20.0
5.0s/times
When F17.08 = 0, it means “auto reset” is disabled and the protective device will be activated in case
of fault.
• If no other fault is detected within 5 minutes, the auto reset count will be automatically cleared.
• On condition of external fault reset, auto reset count will be cleared.
F17.10 Fault relay action select 00
11
00
Units: During auto reset
• 0: Fault relay doesn’t act.
• 1: Fault relay acts.
Tens: During DC bus low
• 0: Fault relay doesn’t act.
• 1: Fault relay acts.
Note: It need preset the relay function as No. 14 function. (Controller fault)
6
