- 27 -
1. Place the rivet on the mandrel.
2. Press start buon and thread on blind rivet nut. While doing so hold the blind rivet nut
as far forward as possible and do not reach into the opening.
3. Hold the start buon down unl the blind rivet nut has been completed threaded on;
the tool stops automacally.
4. Guide the rivet into the hole provided and let the tool process the blind rivet nut by
actuang the start buon.
5. Release the start buon aer the set process has ended.
6. The tool will automacally spin o aer reaching the programmed set stroke or set
force.
DANGER

The traction head is a moving component that heats up during the process
and can cause crushing.
• Under no circumstances should you touch parts of the traction head during
the finish boring process.
1 32
4 4 54
