30
Figure 2-32
remove the cylinder head
Loosen the bolt by intersection manner before remove the bolt.see figure
2-33.
Figure 2-33
remove adjuster cotter sealed ring
of cylinder headtensioner
adjuster guide board
See figure 2-34.
Figure 2-34
remove cylinder block0-seal
adjuster cotter
sealed ring of cylinder head
