44
(Figure 4-1-6)
Figure 4-1-6
1)Tension rod
2)front right Differential
3)cotter pin 3.2*32
4)Hexagon open-groove nut M10
7.Pull out the components of
the steering vertical column
from the bottom seat.
( Figure 4-1-7)
Figure 4-1-7
1、
Steering Vertical Column
2、
Bottom Seat
4.1.1.2 Inspection of steering vertical column components:
1.Check whether the nut between
the inner ball pin of tension
rod and the Turning rocker arm
is tightened.( Figure 4-1-8)
In case of loosen or worn out,
