4.2.1.5 Assembly of Front Brake System
1.Use Fuel Pipe Brackets (2pcs) and Hexagon Flange Bolts
M8*16 (2pcs) to connect the Fuel Pipe Clip with both left
and right Lower Front L/R rocker armss.
Caution: Fuel Pipe must avoid physical contact with
other components in movement.
2、Fix the Disk Brake Plate onto the Front Wheel Hub with M8
Special Bolts (4pcs) (Figure 4-2-4)
Caution: grease the bolt with thread glue when
fastening.Fastening Torque of the Bolt:
22N.M-26N.m
3、 Fix the Front Wheel Hub onto the Front Wheel Shaft with
open-groove nuts and cotter pins. (Figure 4-2-4)
Fastening Torque of Open-groove nut:
50 N.m—60N.m
4、 Fix the Plate Clip onto Front Turning Joint with M8 Bolts
(4pcs)
Fastening Torque: 18 N.m --22 N.m
5、Assemble Front Wheel Components onto Front Wheel Hub
with M10 Conical Nuts of GB/T802 (4pcs) (Figure
