56
4.2.1.4Inspection of the Front Brake System
1.Check the Brake Fluid Box for crack, leakage and other
potential defects.
2.Check Fastening Bolts of all Fuel Pipes for possible looseness
or damage.
3.Check all Fuel Pipes for deterioration, distortion, crack, wear
and other hidden defects.
4.Check the Brake Plate Clip for distortion, crack, rust and stuck.
5.Inspect the Brake Shoe for wear condition. Brake shoe must be
replaced when worn out. (Figure 4-2-8)
Figure 4-2-8
1) Brake Shoe
6、 Inspect the Brake Shoe for maximum wear, distortion and
crack, in which case it must be replaced.
Maximum wear of Rear Disk Brake Plate is less than
