59
a) Brake system is crucial to the life safety of the operator
and therefore must be periodically inspected and
maintained.
b)Rear wheels of the vehicle use brake plates mechanized by a
rear brake pedal. Please follow the tips of inspection as
below.
c)Inspect the brake fluid box level on the right handlebar.
Should the fluid level falls under the minimum mark, please
refill the box with the same type of fluid as was
recommended by the manufacturer (Figure 4-2-9) to ensure
the fluid level is higher than the minimum mark.
Figure 4-2-9
Figure 4-2-9
1、Minimum Mark
d)Travel distance of the Rear Brake Pedal should be kept
between 20mm-30mm. Otherwise, please adjust the screw to
meet required travel distance.( Figure 4-2-10)
