transmission case .Then configure the rear central transmission shaft,
rear transmission case in turn. See
Figure 4-2-15
3、 Mount the Disk Brake Clip onto rear transmission case with M10×30
Bolts (2pcs)
Fastening Torque: 18 N.m--22 N.m
4、 Mount Fluid Box of Rear Disk Brake onto the Frame with M Bolt
(1pcs).
Fastening Torque: 8 N.m—12 N.m
5、Mount Rear Disk Brake Pump onto the Frame with M Bolts (2pcs).
Fastening Torque: 22 N.m—26 N.m
6 Fix front wheel hub onto the front wheel shaft with cushion,
open-groove nuts and cotter pins.
Fastening Torque: 50 N.m—60 N.m
7.Assemble Front Wheel Components onto Front Wheel Hub with M10
Conical Nuts( GB/T802) (4pcs).
Fastening Torque of Conical Nut: 55 N.m - N.m
Caution: Do NOT operate the vehicle immediately after
assembling the brake system. Please apply the
Brake Lever several times to fully engage the
Disk Brake Plate and have the Brake Fluid
