HT THT45 - Technical Specifications

THT45 - THT45W - THT46
EN - 42
9 TECHNICAL SPECIFICATIONS
Temperature measurement
Range
Resolution
Accuracy (*)
-20°C  350.0°C
0.1°C
2%rdg or 2°C (higher value)
-4.0°F  662.0°F
0.1°F
2%rdg or 3.6°F (higher value)
(*) Accuracy referred to environmental temperature within 10°C and 35°C and object temperature >0°C
Temperature measurement in Screening mode
Range
Resolution
Accuracy
32.0°C  42.0°C
0.1°C
0.5°C
89.6°F 107.6°F
0.1°F
0.9°F
General specifications
Type of IR sensor / Resolution: UFPA / (80x80pxl, 34m – TH45, THT45W)
UFPA / (160x120pxl, 25m – TH46)
Spectrum response: 8 14m
Visual range (FOV) / Lens: 17° x 17° (THT45, THT45W), 25°x19°(THT46) / 9mm
IFOV (@ 1m): 3.78mrad (THT45, THT45W), 2.78mrad (THT46)
Thermal sensitivity (NETD): <0.1°C@30°C
Image frequency: 50Hz
Focusing: manual
Minimum focus distance: 0.5m
Temperature readings: °C, °F, K
Available colour palettes: 4 (Iron, Rainbow, Grey, Grey Inverse)
Laser pointer: class 2 according to IEC 60825-1
Built-in illuminator: white LED light
Electronic zoom: x1, x32
Emissivity correction: 0.01 ÷ 1.00 in steps of 0.01
Image adjustment mode: Automatic / Manual
Measuring functions: corrections with emissivity and reflected temperature
Measuring cursors: 3 (Fixed, Max Temp., Min Temp.)
Inbuilt photo camera: 1.3Mpxl, FOV 59°
PiP fusion function: IR in Visual and AUF feature
Video output: HDMI
IR video recording: micro SD card (MP4,1280x960@30fps, Max 60min)
Memory: micro SD card 8GB (>2k JPG images), Max 32GB
PC interface: USB 2.0
Audio output: Yes
Power supply
Internal supply: rechargeable Li-ION battery, 3.7V 2600mAh
External supply: adapter 100-240VAC (50/60Hz)/5VDC
Battery duration: 4 hours of continuous use (WiFi off)
Display
Characteristics: Colour, LCD 2.8”, 320x240pxl
Mechanical characteristics
Size (L x W x H): 224 x 77 x 96mm (9 x 3 x 4in)
Weight (battery included): 0.5kg (10lv)
