Table 5-6 GBTS List tab page
No. Description
1 Toolbar, providing the operation access for commissioning GBTSs. You can
locate the cursor on each icon on the toolbar to learn the meaning of this icon
according to the displayed message.
2 Commissioning task list, displaying all commissioning tasks that you create
and the commissioning progress of each task. You can right-click a task, and
then choose the corresponding item from the shortcut menu to perform a
certain operation.
3 Status bar of commissioning tasks, displaying the total number of
commissioning tasks and number of commissioning tasks in each status.
4 Operation results, that is, the results of the operations that you perform in the
GBTS Auto Deployment window.
Monitor Tab Page
Figure 5-11 shows the Monitor tab page. The Monitor tab page displays all alarms of a certain
GBTS and all relevant alarm of the GBSC managing the GBTS, which are generated during the
commissioning. If the fault cause cannot be located according to the alarm information, you can
select one object or alarm to perform the fault diagnosis. For details about Figure 5-11, see
Table 5-7.
You can select a commissioning task on the GBTS List tab page, and then click
.
Alternatively, right-click the task, and then choose Open Monitor Window from the shortcut
menu to open this tab page.
3900 Series Multi-Mode Base Station
Commissioning Guide
5 Commissioning the MBTS in GL or UL Mode on the
M2000
Issue 02 (2010-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
5-45
