– The IP address is incorrect.
----End
7.2.3 Logging In to the SMT
This section describes how to log in to the base station through the SMT.
Prerequisite
l The SMT client is properly connected to the base station.
l The latest software of the SMT is installed on the SMT client.
Procedure
Step 1 Start the SMT.
l If the connection between the SMT client and the base station is established, a dialog box
shown in Figure 7-2 is displayed. The SMT is successfully started.
l If the SMT client cannot communicate with the base station, the Communication failed
dialog box is displayed, as shown in Figure 7-3. Go to Step 2.
Figure 7-2 SMT login interface
7 Commissioning the MBTS by Using Local Maintenance
Terminal and M2000
3900 Series Multi-Mode Base Station
Commissioning Guide
7-8 Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue 02 (2010-07-30)
