Panel
The panel of the eA660 provides the Power over Ethernet (PoE) port, SIM card maintenance
window, and indicator.
Figure 2-2 shows the panel of the eA660.
Figure 2-2 Panel of the eA660
Table 2-1 lists the ports of the eA660.
Table 2-1 Ports on the eA660
Name
Description
PoE
PoE port
LED
Indicators
SIM card maintenance window
Consists of the SIM card slot and USB port.

A SIM card is inserted into the SIM card
slot.

The USB port is used for internal
commissioning.
Grounding end
Connects a ground cable
