eA660 Series CPE
User Guide
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Figure 3-28 Fixing the wall-mounting frame
Step 5 Install the ground cable. For details, see Step 1 in Cable Connection.
Step 6 Fix eA660 to the wall-mount frame using the dovetail groove, as shown in Figure 3-29.
Figure 3-29 Fixing the CPE
Step 7 Tighten the wall-mounting frame's screw, as shown in Figure 3-30.
