2.1 Front Panel
2.1.1 Appearance
● 4 x 3.5" drive
conguration
Figure 2-1 Front view
1
Drives 2 Slide-out label plate
(with an SN label)
FusionServer Pro 1288H V5 Server
User Guide 2 Hardware Description
