● 8 x 2.5" drive conguration
Figure 2-2 Front view
1 Drives 2 (Optional) Built-in DVD
drive
3 Slide-out label plate
(with an SN label)
- -
● 10 x 2.5" drive
conguration
Figure 2-3 Front view
1 Drives 2 Slide-out label plate
(with an SN label)
2.1.2 Indicators and Buttons
Positions
● 4 x 3.5" drive
conguration
Figure 2-4 Indicators and buttons on the front panel
