OptiX RTN 600 Product Description
Commercial in Confidence Page 12 of 44
Available Slot
Board
Name
Full Name
IDU 610 IDU 620
Description
SL1
SDH single STM-1
port board
 Uses the SFP optical module to
provide one STM-1 optical
interface.
SD1
SDH dual STM-1 port
board
 Uses the SFP optical module to
provide two STM-1 optical
interfaces.
SLE
SDH single STM-1
electrical port board
 Provides one 75-ohm STM-1
electrical interface.
SDE
SDH dual STM-1
electrical port board
 Provides two 75-ohm STM-1
electrical interfaces.
PO1 8xE1 tributary board
 Provides eight 75/120-ohm E1
interfaces.
PH1 16xE1 tributary board
Slot 3/4
Slot
4/5/6/7/8
 Provides 16 75/120-ohm E1
interfaces.
FAN Fan board - Slot 20 -
3.2.2 ODU
The ODU is the outdoor unit of the OptiX RTN 600 system. It performs frequency
conversion and amplification for RF signals.
The ODU is an integrated system and has various types. Different types of ODUs
have the same structure and conform to the same working principle. They only differ
in terms of the operating frequency band, sub-band, T/R spacing, and higher/lower
station.
