Chapter 7 Performance
7.1 Radio Performance
7.1.1 Frequency Band
Table 7-1 Frequency band
Performance
Item
7 GHz 15 GHz 18 GHz 23 GHz
Frequency range (GHz)
7.114 to
7.743
14.501 to
15.257
17.685 to 19.710
22.000 to
23.608
T/R spacing (MHz) 161 420 1010 1008
Channel spacing (MHz) 3.5, 7, 14, 28 3.5, 7, 14, 28 3.5, 7, 13.75, 27.5 3.5, 7, 14, 28
7.1.2 Receiver Sensitivity
Table 7-2 Receiver sensitivity
Performance
4xE1 8xE1 16xE1 STM-1
Item
QPSK 16QAM QPSK 16QAM QPSK 16QAM 128QAM
RSL@ BER=10
-6
(dBm)
@ 7GHz -91.5 -87.5 -88.5 -84.5 -85.5 -81.5 -70.5
@ 15GHz -91.0 -87.0 -88.0 -84.0 -85.0 -81.0 -70.0
@ 18GHz -91.0 -87.0 -88.0 -84.0 -85.0 -81.0 -70.0
@ 23GHz -90.5 -86.5 -87.5 -83.5 -84.5 -80.5 -69.5
