Quidway AR 28 Series Routers Installation Manual Chapter 1 Overview
Huawei Technologies Proprietary
1-4
Table 1-1 Interfaces and slots on AR 28 Series Routers
Item
AR
28-09
AR
28-10
AR
28-11/
13/14
AR
28-12
AR
28-30
AR
28-31
AR
28-40
AR
28-80
AUX
port
1 1 1 1 1 1 1 1
Conso
le port
1 1 1 1 1 1 1 1
Fixed
WAN
port
1 1 1 2 –– –– –– ––
Fixed
LAN
port
1 1 2 2 1 2 –– ––
Exten
ded
SIC
2 2 2 2 –– –– –– ––
Exten
ded
MIM
1 1 1 1 3 3 4 8
Note:
The fixed synchronous/asynchronous interface of the AR 28-10/28-11 matches a
DB-50 connector, and AR 28-12 match DB-28 connector. The fixed WAN interface for
the AR 28-13 is CE1/PRI, and that for the AR 28-14 is CT1/PRI.
1.3 MIM and SIC
AR 28-09/28-10/28-11/28-12/28-13/28-14 provides two SIC slots and one MIM slot; AR
28-30 provides three MIM slots; AR 28-40 provides four MIM slots; AR 28-80 provides
eight MIM slots. AR 28 Series Routers can fully meet clients’ needs for function
extension to router.
1.3.1 MIM
Quidway AR 28 Series Routers support these types of MIM modules:
z Ethernet interface modules
1-port 10Base-T/100Base-TX Fast Ethernet interface module (1FE)
2-port 10Base-T/100Base-TX Fast Ethernet interface module (2FE)
1-port 100Base-FX Ethernet multi-mode fiber interface module (1MFX)
